Tilton Overhung Mount 2 Pedal Box 600 Series
by Tilton
$1,206.72 NZD
SKU Tilton-OM-2PB-800
Buy now pay later,no extra cost!
Payments from $120.67 with
Enjoy now. Pay Later. Interest free. Learn More
Tilton’s 800-Series overhung pedal assembly merges the performance of 900-Series pedal assembly technology and the renowned value of 600-Series pedal assemblies. Features high-efficiency spherical bearing type balance bar and pivot-mount master cylinder design.
Features:
- High-efficiency balance bar and pivot-mount master cylinder design
- Forged aluminium pedals are engineered for high rigidity and low weight.
- Adjustable pedal ratios (5.0:1 – 6.2:1) enable the brake pedal to be tuned to driver preference without having to change master cylinder bore size.
- Footpads can be adjusted vertically, horizontally and in angle to suit individual driver preferences
- Large diameter 7/16”-20 balance bar provides maximum rigidity. PTFE coated aluminium clevises for increased durability and reduced friction.
- Pedal pivots feature wave washers to reduce lateral pedal movement and oil-impregnated bronze bushings decrease stiction.
- The lightweight aluminium frame features guide “ramps” to reduce balance bar tipping, decreasing friction and improving brake repeatability.
Master Cylinders (sold separately):
Brakes: 78 or 79 Series master cylinders
Clutch: 76 Series master cylinders
