Mishimoto Honda Civic SI Performance Aluminum Radiator, 2002-2005
by Mishimoto
Save 15%
Original Price
$907.20 NZD
Current Price
$771.12 NZD
SKU misMMRAD-CIV-02SI
Buy now pay later,no extra cost!
Payments from $77.11 with
Enjoy now. Pay Later. Interest free. Learn More
A Mishimoto performance aluminum radiator is the ideal upgrade to the stock Civic radiator. For a cooler more efficient running engine, all Mishimoto radiators are designed and engineered to maximize cooling, boost engine functions, and most importantly prevent your car from overheating. Made with 100% brazed aluminum and polished end tanks, this lightweight dual core radiator will enhance the overall performance and lifetime of your engine. This aluminum radiator, like all Mishimoto radiators, comes with a 1.3 bar high-pressure radiator cap and is backed by our unparalleled Mishimoto Lifetime Warranty.
- Fits USDM EP3 Civic SI (2002–2005)
- Fits UKDM EP3 Civic Type R (2002–2005)
Features:
- Direct fit for the 2002–2005 Honda Civic Si w/ K20 engine
- Full aluminum construction with durable TIG-welded end tanks
- Features a two-row, 1.42" thick brazed aluminum core which provides efficient fluid temperature regulation on the street and track
- Features a two-row, 1.42" thick brazed aluminum core which provides efficient fluid temperature regulation on the street and track
- Features a two-row, 1.42" thick brazed aluminum core which provides efficient fluid temperature regulation on the street and track
- Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system
- Mishimoto Lifetime Warranty
Purchase Includes:
- Mishimoto Radiator
- Mishimoto Radiator Cap
- Magnetic Drain Plug
- Mishimoto Lifetime Warranty
Notes:
This item is for Manual Transmission vehicles. For automatic applications, please purchase optional Mishimoto Universal Transmission Cooler Kit.
Vehicle Specifications:
| Engine Codes | K20a3 |
| Chassis Codes | EP3 |
| Fits | 2002-2005 UKDM EP3 Civic Type R |
Product Specifications:
| Material | Aluminum |
| Overall Height | 17.95" |
| DPI | 2574 |
| Drain Plug Length | 0.047" |
| Drain Plug Thread Size | (M12) x 1.5 |
| Overall Length | 26.93" |
| Fill Neck Thickness | 0.12" |
| Tank Wall Thickness | 0.08" |
| Outlet | 1.26" |
| Rows | 2 |
| Inlet | 1.26" |
| Coolant Capacity | 1.58 |
| Dual Pass | False |
| Overall Width | 1.92" |
| Core Length | 13.78" |
| Core Height | 26.23" |
| Core Thickness | 1.42" |
| Fill Neck | 1.22" |
| Overall Length (in) | 26.93 |
| Overall Height (in) | 17.95 |
| Overall Width (in) | 1.92 |
| Rows | 2 |
